Ciw Call Centre Model from JSON

On this page we will create a ciw network model from a specification in a JSON file.

The model represents a simple urgent care call centre defined in Monks and Harper (2023)

Call centre diagram

1. Imports

1.1 json2ciw imports

We will use:

  • load_call_centre_model function that loads the built in urgent care call centre JSON file.
  • ProcessModel: a pydantic schema that provides automatic validation of the JSON.
  • CiwConverter that accepts a valid ProcessModel that represents a DES model and returns a ciw parameter dict.
  • multiple_replications:runs the network model and results a Dataframe of replication results.
  • summarise_results: provides a formatted table of mean results for each node in the network.
  • tidy_to_wide_format: the results from multiple_replications are returned in tidy (stacked row) format. This function converts into wide format i.e. each column is a performance measure.
  • create_user_filtered_hist generates a interactive plotly chart to view replications for each performance measure. It requires replication data in wide format.
from json2ciw.datasets import load_call_centre_model
from json2ciw.engine import (
    CiwConverter,
    multiple_replications
)
from json2ciw.results import (
    summarise_results,
    create_user_filtered_hist,
    tidy_to_wide_format
)

from json2ciw.schema import ProcessModel

1.2 Other imports

import ciw
import statistics
from IPython.display import JSON
from rich import print

2. Load JSON

json_call_centre = load_call_centre_model()

display as collapsible JSON. Expand to view the details.

JSON(json_call_centre)
<IPython.core.display.JSON object>

3. Convert to a ProcessModel

A ProcessModel is a pydantic schema. It is independent of ciw. This early version will automatically validate that the JSON file is correct and that all transitions add up to 1.0 when it is created.

model_instance = ProcessModel(**json_call_centre)

The contents of the process model can be manually inspected by a developer as follows:

print(model_instance)
ProcessModel(
    name='Call Handling Process',
    description='Discrete Event Simulation of a Patient call handling process.',
    activities=[
        Activity(
            name='Call Triage',
            type='activity',
            resource=Resource(name='Operator', capacity=13),
            service_distribution=Distribution(
                type='triangular',
                parameters={'min': 5.0, 'mode': 7.0, 'max': 10.0}
            ),
            arrival_distribution=Distribution(type='exponential', parameters={'mean': 0.6}),
            renege_distribution=None
        ),
        Activity(
            name='Nurse Consultation',
            type='activity',
            resource=Resource(name='Nurse', capacity=9),
            service_distribution=Distribution(type='uniform', parameters={'min': 10.0, 'max': 20.0}),
            arrival_distribution=None,
            renege_distribution=None
        )
    ],
    transitions=[
        Transition(source='Call Triage', target='Nurse Consultation', probability=0.4),
        Transition(source='Call Triage', target='Exit', probability=0.6),
        Transition(source='Nurse Consultation', target='Exit', probability=1.0)
    ]
)

model_instance.display_diagram()
graph TD
    %% Call Handling Process: Discrete Event Simulation of a Patient call handling process.
    Arrivals_Call_Triage("Time between arrivals<br/>Exponential(mean=0.6)")
    Call_Triage["Call Triage<br/>Triangular(5.0, 7.0, 10.0)"]
    Nurse_Consultation["Nurse Consultation<br/>Uniform(10.0, 20.0)"]
    Resource_Operator(("Operator<br/>(13)"))
    Resource_Nurse(("Nurse<br/>(9)"))
    Exit(["Exit"])

    Arrivals_Call_Triage --> Call_Triage
    Resource_Operator -.Seize.-> Call_Triage
    Call_Triage -.Release.-> Resource_Operator
    Resource_Nurse -.Seize.-> Nurse_Consultation
    Nurse_Consultation -.Release.-> Resource_Nurse
    Call_Triage -->|40%| Nurse_Consultation
    Call_Triage -->|60%| Exit
    Nurse_Consultation --> Exit
# summary of distribution used
model_instance.get_distributions_df()
Activity Phase Distribution Type Parameters
0 Call Triage Arrival Exponential mean=0.6
1 Call Triage Service Triangular min=5.0, mode=7.0, max=10.0
2 Nurse Consultation Service Uniform min=10.0, max=20.0
# summary of routing percentages
model_instance.get_routing_matrix_df()
Call Triage Nurse Consultation Exit
Source Activity
Call Triage 0.0 0.4 0.6
Nurse Consultation 0.0 0.0 1.0
# resources included
model_instance.get_resources_df()
Resource Activity Count
0 Operator Call Triage 13
1 Nurse Nurse Consultation 9

3. Convert to a ciw Network Model

adapter = CiwConverter(model_instance)
network_params = adapter.generate_params()

The variable network_params is a python dict that contains all the parameters that ciw requires for a very simple queuing model. This can be passed as keyword args to the ciw.create_network function.

network_params
{'number_of_servers': [13, 9],
 'arrival_distributions': [Exponential(rate=1.6666666666666667), None],
 'service_distributions': [Triangular(lower=5.0, mode=7.0, upper=10.0),
  Uniform(lower=10.0, upper=20.0)],
 'reneging_time_distributions': [None, None],
 'routing': [[0.0, 0.4], [0.0, 0.0]]}
# we use ciw's native `create_network` method
network = ciw.create_network(**network_params)
print(type(network))
<class 'ciw.network.Network'>

# Run a quick simulation to verify it works without crashing...
sim = ciw.Simulation(network)
sim.simulate_until_max_time(50)
print("Quick simulation run worked!")
Quick simulation run worked!

4. Run the model for multiple replications

The multiple_replications function returns a DataFrame that contains one row per activity per replication. So if there are two nodes there are two rows for each replication.

# Run replications with activity/resource names
df_reps = multiple_replications(
    network,
    model_instance,
    num_reps=100,
    runtime=2880,
    warmup=1440,
    n_jobs=-1 # parallel reps
)

df_reps.head()
rep node_id activity_name resource_name resource_capacity n_service mean_wait mean_service utilisation mean_Lq
0 0 1 Call Triage Operator 13 2409 2.543220 7.309819 95.129252 4.254594
1 0 2 Nurse Consultation Nurse 9 765 206.954675 14.990006 99.164671 109.944671
2 1 1 Call Triage Operator 13 2370 2.795481 7.321618 93.117043 4.600896
3 1 2 Nurse Consultation Nurse 9 773 224.244232 14.981693 99.525047 120.375549
4 2 1 Call Triage Operator 13 2426 4.816395 7.323897 95.099958 8.114287

Filter the nodes with the usual pandas syntax

df_reps.loc[df_reps['activity_name'] == "Call Triage"].head(3)
rep node_id activity_name resource_name resource_capacity n_service mean_wait mean_service utilisation mean_Lq
0 0 1 Call Triage Operator 13 2409 2.543220 7.309819 95.129252 4.254594
2 1 1 Call Triage Operator 13 2370 2.795481 7.321618 93.117043 4.600896
4 2 1 Call Triage Operator 13 2426 4.816395 7.323897 95.099958 8.114287

5. Summarise results

If needed there is a built in function to create a DataFrame that contains a mean summary of all metrics across the nodes.

# Get summary table
summary = summarise_results(df_reps)
summary.round(1)
activity Metric Call Triage (Operator) Nurse Consultation (Nurse)
0 Mean completed services 2386.3 763.6
1 Mean waiting time 4.0 216.1
2 Mean service time 7.3 15.0
3 Mean utilisation 93.9 99.3
4 Mean queue length 6.6 113.7
wide = tidy_to_wide_format(df_reps)
wide.head()
n_service [Call Triage] n_service [Nurse Consultation] mean_wait [Call Triage] mean_wait [Nurse Consultation] mean_service [Call Triage] mean_service [Nurse Consultation] utilisation [Call Triage] utilisation [Nurse Consultation] mean_Lq [Call Triage] mean_Lq [Nurse Consultation]
rep
0 2409 765 2.543220 206.954675 7.309819 14.990006 95.129252 99.164671 4.254594 109.944671
1 2370 773 2.795481 224.244232 7.321618 14.981693 93.117043 99.525047 4.600896 120.375549
2 2426 761 4.816395 228.917962 7.323897 14.812186 95.099958 99.342764 8.114287 120.976784
3 2308 725 3.124735 243.422767 7.351322 15.043528 92.053435 99.140463 5.008256 122.556602
4 2449 752 4.211408 246.921582 7.334381 14.992293 94.982781 99.548895 7.162318 128.947937
